| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | GE0833 | CABLE ASSEMBLY - 102" LONG | 1 | ||||
| ? | GE0832 | CABLE ASSEMBLY - 108" LONG | 1 | ||||
| ? | VS9089 | STRAP, CONNECTION | 2 | ||||
| ? | VS9086 | STRAP, CONNECTION | 2 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | 16 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 16 | ||||
| ? | VE4642 | CAPSCREW - 1/4" - 20NC X 5/8" | 14 | ||||
| ? | VE4630 | CAPSCREW - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 16 | ||||
| ? | VE4332 | TAPE | |||||
| ? | VE4335 | TAPE, FIBERGLASS | |||||
| ? | VE3915 | VARNISH - 1 GALLON | |||||
| ? | 58D-06-01160 | COIL, EXCITING | 4 | ||||
| ? | VS9084 | PIECE, POLE | 4 | ||||
| ? | VS9087 | STRAP, CONNECTION | 2 | ||||
| ? | 58E-06-09150 | COIL, COMMUTATING | 4 | ||||
| ? | VS9083 | PIECE, POLE | 4 | ||||
| ? | C1630 | CAPSCREW - 5/8" - 11NC X 2" | 16 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 16 | ||||
| ? | VS9088 | STRAP, CONNECTION | 1 | ||||
| ? | VE4832 | PIN, DOWEL | 2 | ||||
| ? | VE4835 | BUSHING (1) | 2 | ||||
| ? | VS7010 | SLEEVE (1) | 1 | ||||
| ? | XA4248 | FRAME, MAGNET | 1 | ||||
| ? | 58F-GB-AK010 | NOTE: (1) INCLUDED IN 58F-GB-AK010 BLOWER MOTOR KIT. |
