| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VC1390 | LOCKWASHER - 5/8" | 16 | ||||
| ? | C1630 | CAPSCREW - 5/8" - 11NC X 2" | 16 | ||||
| ? | BF1890 | ARMATURE ASSEMBLY | 1 | ||||
| ? | VE4818 | PUNCHING, MAIN (1) | 256 | ||||
| ? | VE4819 | PUNCHING, END (1) | 4 | ||||
| ? | VE7206 | TAPE, FIBERGLASS (1) | |||||
| ? | VE2761 | ARMATURE REWIND KIT (1) | 1 | ||||
| ? | XA4214 | VARNISH (1) | |||||
| ? | VE4687 | LOCKWASHER - 3/8" | 8 | ||||
| ? | VE4641 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 8 | ||||
| ? | VE8978 | SEAL, V-RING (2) | 1 | ||||
| ? | VE4257 | FAN | 1 | ||||
| ? | XA4244 | FRAME, HEAD | 1 | ||||
| ? | XA4242 | GASKET | 1 | ||||
| ? | VS9031 | LOCKWASHER - 1 23/32" ID | 1 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 6 | ||||
| ? | TR4731 | CAPSCREW - 5/16" - 18NC X 1" | 6 | ||||
| ? | VS8884 | NUT - 1 11/16" | 1 | ||||
| ? | BF1889 | PIN, COTTER (2) | 1 | ||||
| ? | VS9062 | NUT - 1 1/8" | 1 | ||||
| ? | BF0997 | SHAFT (1) | 1 | ||||
| ? | XA4243 | CAP, BEARING | 1 | ||||
| ? | VS9262 | BEARING, BALL (2) | 1 | ||||
| ? | VS9032 | FLINGER | 1 | ||||
| ? | VS9061 | WEIGHT, BALANCE (1) | |||||
| ? | BF0998 | HEAD, ARMATURE (1) | 1 | ||||
| ? | BF1890 | NOTE: (1) INCLUDED IN BF1890 ARMATURE ASSEMBLY. | |||||
| ? | 58F-GB-AK010 | (2) INCLUDED IN 58F-GB-AK010 BLOWER MOTOR KIT. |
