Содержание Dump Trucks Komatsu AFE62-BY 930E-4SE S/N A32132 - A32133 EPSA(AFE62-BY)
CONTROL CABINET 4/11 58B-43-01001(644 : 68904)
Номер на схеме Каталожный номер Название Количество Детали
? XA4876 CAPACITOR, IGBT INVERTER 10
? VE4655 FLAT WASHER - #10
? VE4601 LOCKWASHER - #10
? SF2755 NUT - #10 - 32NF
? 58B-43-00280 LOCKNUT - 3/8" - 16NC 4
? XA2784 WASHER
? 58D-98-00950 BUS BAR 1
? 58D-98-00880 MODULE, CPD 1
? VE4343 FLAT WASHER - 5/16"
? VE4699 LOCKWASHER - 1/2"
? VE4696 LOCKWASHER - 5/16"
? VE5013 NUT - 5/16" - 18NC
? 58E-43-00061 POWER SUPPLY 1
? AK1960 FLAT WASHER, NARROW - 5/16"
? 58D-98-02180 FLAT WASHER - 1/4"
? DC3584 LOCKWASHER - 1/4"
? VE7202 WASHER - 1/4"
? GE0588 INSULATOR 2
? 58D-98-01000 MACHINE SCREW - #10 - 32NF X 1"
? GE0240 GROMMET 2
? VE5169 FLAT WASHER - 5/8"
? VC1390 LOCKWASHER - 5/8"
? GE0045 NUT - 5/8" - 11NC
? GE0862 STUD 12
? TD1549 NUT - 1/4" - 20NC
