| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-60-11031 | AUTOMATIC FILL CONTROL (AFC) BOX (1) | 1 | ||||
| ? | TD1809 | CAPSCREW - 1/4" - 20NC X 3/4" | 6 | ||||
| ? | TR1307 | FLAT WASHER - 1/4" | 12 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 6 | ||||
| ? | EK0195 | PLATE, MOUNTING | 2 | ||||
| ? | MM0713 | FLAT WASHER, HARDENED - M10 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 21 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 21 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 8 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 22 | ||||
| ? | WB1303 | CLAMP, CUSHIONED - 3/4" | 2 | ||||
| ? | WB1184 | NUT, COUPLING | 2 | ||||
| ? | EK9883 | SPACER | 5 | ||||
| ? | 58B-06-20020 | BRACKET | 6 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 11 | ||||
| ? | TY8375 | SPACER | 5 | ||||
| ? | 58B-06-10291 | HARNESS, WIRING - ENGINE OIL RESERVE SYSTEM | 1 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 1 | ||||
| ? | SD5211 | BUSHING, PIPE | 1 | ||||
| ? | 58F-06-10830 | SWITCH, THERMOSTAT | 1 | ||||
| ? | WB3855 | CLAMP, CUSHIONED - 13/16" | 13 | ||||
| ? | MM0603 | CAPSCREW - M10 X 1.50 X 16 | 2 | ||||
| ? | EM1393 | SPACER | 2 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 3 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 4 | ||||
| ? | 08192-12100 | BODY, RECEPTACLE CONNECTOR | 2 | ||||
| ? | 08193-21012 | CLIP | 2 | ||||
| ? | 58E-09-00000 | PLATE | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 1 | ||||
| ? | WB1305 | CLAMP, CUSHIONED - 1 1/2" | 1 | ||||
| ? | 58E-61-00210 | NOTE: (1) INCLUDED IN 58E-61-00210 RESERVE SYSTEM KIT. (SEE INDEX) | 45777 |
