Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EG0583 |
MOUNT, INJECTOR |
1 |
|
|
|
|
? |
MM0606 |
CAPSCREW - M10 X 1.50 X 30 |
6 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
12 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
6 |
|
|
|
|
? |
EJ4053 |
PLATE, MOUNTING |
1 |
|
|
|
|
? |
TA4411 |
INJECTOR ASSEMBLY, REAR - 5 PIECE (SEE INDEX) |
1 |
|
69805 |
|
|
? |
VW7989 |
INJECTOR ASSEMBLY, REAR - 4 PIECE (SEE INDEX) |
2 |
|
69804 |
|
|
? |
VW7990 |
CAP, PROTECTIVE |
13 |
|
|
|
|
? |
MM0611 |
CAPSCREW - M10 X 1.50 X 60 |
6 |
|
|
|
|
? |
WB0252 |
FITTING, ELBOW - 90 DEG |
13 |
|
|
|
|
? |
WB0262 |
FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
? |
TB8803 |
NIPPLE, PIPE - 3/8" |
2 |
|
|
|
|
? |
R0086 |
BUSHING, PIPE - 1/4" X 3/8" |
1 |
|
|
|
|
? |
HA2995 |
HOSE (TO REAR AXLE PIVOT) |
1 |
|
|
|
|
? |
58F-60-41700 |
FITTING, TEE |
1 |
|
|
|
|
? |
58E-06-60390 |
SWITCH, PRESSURE |
1 |
|
|
|
|
? |
C5769 |
PLUG, PIPE - 1/4" |
1 |
|
|
|
|
? |
58F-60-50970 |
HOSE (TO UNION FIT) |
1 |
|
|
|
|
? |
HA1413 |
HOSE (TO BOTTOM OF REAR SUSPENSIONS) |
2 |
|
|
|
|
? |
HA8637 |
HOSE (TO BOTTOM OF HOIST CYLINDERS) |
2 |
|
|
|
|
? |
HA1413 |
HOSE (TO LH END OF SWAY BAR) |
1 |
|
|
|
|
? |
HA0197 |
HOSE (TO TOP OF REAR SUSPENSIONS) |
2 |
|
|
|
|
? |
VD4661 |
HOSE (TO BODY PIVOT PINS) |
2 |
|
|
|
|
? |
HA0394 |
HOSE (TO TOP OF HOIST CYLINDERS) |
2 |
|
|
|
|
? |
HA0570 |
HOSE (TO RH END OF SWAY BAR) |
1 |
|
|
|
