| Наименование | Страница | Код страницы |
|---|---|---|
| 3-PIECE INJECTOR ASSEMBLY TA4410 | 606 | 69863 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0178 | NUT - M10 X 1.50 | 6 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 6 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 10 | ||||
| ? | EM1393 | SPACER | 6 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 6 | ||||
| ? | 58F-60-50960 | HOSE | 1 | ||||
| ? | WB0252 | FITTING, ELBOW - 90 DEG | 4 | ||||
| ? | HA0570 | HOSE | 2 | ||||
| ? | WB0281 | FITTING, ELBOW - 45 DEG | 2 | ||||
| ? | 58F-60-40690 | HOSE | 4 | ||||
| ? | WB0462 | FITTING, STRAIGHT | 1 | ||||
| ? | 58B-60-20640 | HOSE | 1 | ||||
| ? | WB0289 | FITTING, ELBOW - 45 DEG | 2 | ||||
| ? | WB0384 | FITTING, TEE | 1 | ||||
| ? | 58B-60-20730 | HOSE | 1 | ||||
| ? | C5770 | PLUG, PIPE - 3/8" | 1 | ||||
| ? | MM0609 | CAPSCREW - M10 X 1.50 X 45 | 4 | ||||
| ? | TA4410 | INJECTOR ASSEMBLY, 3-PIECE (SEE INDEX) | 2 | 69863 | |||
| ? | VW7990 | CAP, PROTECTIVE | 6 |
