Номер на схеме	Каталожный номер	Название	Количество
?	WB3239	NAME PLATE - 12 VCN	1
?	58E-06-00514	HARNESS, WIRING - AUXILIARY CONTROL CABINET INTERNAL	1
?	58B-06-00290	• VARISTOR	3
?	58B-06-00160	• RESISTOR - 560 OHM, 3W	1
?	58B-06-00130	• RESISTOR - 1 KOHM, 2W	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	2
?	SP8417	FLAT WASHER - 1/4"	2
?	SD5390	MACHINE SCREW - #10 - 32NF X 1"	2
?	VC5344	FLAT WASHER - #10	2
?	DC3101	LOCKWASHER - #10	2
?	ED4418	BRACKET	1
?	PB8460	CIRCUIT BREAKER	1
?	XC2504	BRACKET, LIGHT	1
?	PC3010	LIGHT, DOME	1
?	PC1507	MACHINE SCREW - #8 - 32NC X 1"	4
?	PC1516	NUT - #8 - 32NC	4
?	EC7460	NAME PLATE - DL4	1
?	58E-06-40530	NAME PLATE - PLM 4	1
?	WB4010	NAME PLATE - CAN RPC	1
?	58E-06-10540	RETAINER, WIRE DUCT - 2"	4
?	XC2513	BRACKET	1
?	PB8256	SCREW LOCK, FEMALE	3
?	58E-06-10590	NAME PLATE - DATA PORTS	1
?	58E-06-10821	HARNESS, WIRING - 1939 JUMPER (CAN RPC JUMPER)	1
?	58E-06-07561	CABLE, CAT5E - PLM 4	1
?	58B-06-10400	COMMUNICATION INTERFACE, PAYLOAD METER 4	1
?	58E-06-20350	CAPSCREW - M8 X 1.25 X 110	4
?	MM0470	LOCKWASHER - M8	4
?	MM0460	FLAT WASHER - M8	4
?	58E-06-08031	HARNESS, WIRING - PLM 4/AUXILIARY BOX	1
?	MM0176	NUT - M6 X 1.00	6
?	MM0469	LOCKWASHER - M6	6
?	MM0459	FLAT WASHER - M6	6
?	PC1110	CONVERTOR, 24V TO 12V	1
?	MM0585	CAPSCREW - M6 X 1.00 X 35	4
?	01643-30623	WASHER - M6	4
?	58E-06-08151	PLATE	1
?	58E-06-40520	NAME PLATE - CAN	1
?	58B-06-10000	CONTROLLER, PAYLOAD METER 4	1
?	58E-06-00410	COVER, WIRING (24-12 VDC, 60 AMP)	2
?	58E-06-00390	DUCT, WIRE	2
?	WB3479	NAME PLATE - CB60	1
