| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB3095 | CLAMP, CUSHIONED - 2 1/4" | 1 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 2 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 2 | ||||
| ? | 58E-65-00001 | CIRCUIT ID (TB21) | 1 | ||||
| ? | 58E-06-11181 | CIRCUIT ID (TB25) | 1 | ||||
| ? | 58E-06-11190 | CIRCUIT ID (TB29) | 1 | ||||
| ? | 58E-06-00380 | COVER, WIRING | 1 | ||||
| ? | 58E-06-00370 | DUCT, WIRING | 1 | ||||
| ? | 58E-06-07550 | CIRCUIT ID (TB33) | 1 | ||||
| ? | 58E-06-00430 | COVER, WIRING | 1 | ||||
| ? | 58E-06-00420 | DUCT, WIRING | 1 | ||||
| ? | 58E-06-10550 | RETAINER, WIRE DUCT - 5" | 15 | ||||
| ? | 58E-06-10540 | RETAINER, WIRE DUCT - 2" | 18 | ||||
| ? | MM0373 | NUT - M5 X 0.8 | 20 | ||||
| ? | MM0379 | LOCKWASHER, EXTERNAL TOOTH - M5 | 20 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 20 | ||||
| ? | PB5732 | TERMINAL BOARD | 16 | ||||
| ? | WB3993 | CIRCUIT ID (TB30) | 1 | ||||
| ? | 58E-65-00041 | CIRCUIT ID (TB34) | 1 | ||||
| ? | 58E-65-00030 | CIRCUIT ID (TB31) | 1 | ||||
| ? | 58E-06-40650 | CIRCUIT ID (TB35) | 1 | ||||
| ? | 58E-06-10772 | CIRCUIT ID (TB32) | 1 | ||||
| ? | 58E-06-40660 | CIRCUIT ID (TB36) | 1 | ||||
| ? | 58E-06-00340 | COVER, WIRING | 1 | ||||
| ? | 58E-06-00331 | DUCT, WIRING | 1 | ||||
| ? | WB3991 | CIRCUIT ID (TB28) | 1 | ||||
| ? | 58E-06-00360 | COVER, WIRING | 3 | ||||
| ? | 58E-06-00350 | DUCT, WIRING | 3 | ||||
| ? | 58E-06-10760 | CIRCUIT ID (TB24) | 1 | ||||
| ? | 58E-06-09840 | COVER, WIRE | 1 | ||||
| ? | 58E-06-09550 | RETAINER, WIRE DUCT | 1 | ||||
| ? | 58E-06-10360 | SCREW, FLANGE - #10 - 24NC X 3/4" | 26 | ||||
| ? | 58E-06-10350 | NUT, RIBBED - #10 - 24NC | 26 | ||||
| ? | 58E-65-00021 | CIRCUIT ID (TB27) | 1 | ||||
| ? | 58E-06-10751 | CIRCUIT ID (TB23) | 1 | ||||
| ? | WB3989 | CIRCUIT ID (TB26) | 1 | ||||
| ? | 58E-06-11171 | CIRCUIT ID (TB22) | 1 | ||||
| ? | VM2951 | SCREW - #6 - 32NC X 5/16" | 32 | ||||
| ? | TR4731 | CAPSCREW - 5/16" - 18NC X 1" | 9 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 9 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 9 | ||||
| ? | 58E-06-02691 | PLATE | 1 | ||||
| ? | WA3367 | NUT ASSEMBLY - #10 - 32NC | 320 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 1 | ||||
| ? | EB7418 | BUS BAR | 12 |
