| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 08038-00035 | CAP, TERMINAL | 5 | ||||
| ? | CH4503 | CABLE (BLACK) | 1 | ||||
| ? | 58B-06-21100 | CABLE (BLACK) | 1 | ||||
| ? | 58B-06-21090 | CABLE (BLACK) | 1 | ||||
| ? | 08038-02027 | CAP, TERMINAL | 2 | ||||
| ? | 58B-06-04500 | CABLE (RED) | 1 | ||||
| ? | 58B-06-21070 | CABLE (RED) | 1 | ||||
| ? | 58B-06-21080 | CABLE (RED) | 1 | ||||
| ? | 58B-06-21040 | HARNESS, WIRING - ENGINE EXTERNAL | 1 | ||||
| ? | 58B-06-21060 | HARNESS, WIRING - CRANKING MOTOR / ALTERNATOR | 1 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 9 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 31 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 32 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 19 | ||||
| ? | EJ3891 | CLAMP ASSEMBLY | 20 | ||||
| ? | WB1303 | CLAMP, CUSHIONED - 3/4" | 10 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 16 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 16 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 16 | ||||
| ? | EL1939 | ROD, THREADED | 10 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 1 | ||||
| ? | WB1301 | CLAMP, CUSHIONED - 1/4" | 5 | ||||
| ? | TY8375 | SPACER | 2 | ||||
| ? | PC1112 | CLAMP ASSEMBLY | 7 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 22 | ||||
| ? | TR4436 | FLAT WASHER, HARDENED - 3/8" | 11 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 11 | ||||
| ? | WB3094 | CLAMP, CUSHIONED - 1 3/4" | 2 | ||||
| ? | VF4084 | CAPSCREW - 3/8" - 16NC X 1" | 1 | ||||
| ? | 08038-04030 | CAP, TERMINAL | 2 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 2 | ||||
| ? | EM3364 | ROD, THREADED | 6 | ||||
| ? | R0086 | BUSHING, PIPE - 1/4" X 3/8" | 1 | ||||
| ? | MM0047 | CAPSCREW - M10 X 1.50 X 30 | 1 |
