| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-54-01771 | HANDRAIL, RETARDING GRID - REAR | 1 | ||||
| ? | 58F-54-01822 | HANDRAIL, RETARDING GRID - FRONT | 1 | ||||
| ? | 58F-54-20291 | HANDRAIL, RH DECK (REAR) | 1 | ||||
| ? | 58F-54-20270 | HANDRAIL, RH DECK (FRONT) | 1 | ||||
| ? | MM0618 | CAPSCREW - M12 X 1.75 X 30 | 22 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 44 | ||||
| ? | MM0714 | FLAT WASHER, HARDENED - M12 | 61 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 22 | ||||
| ? | MM0619 | CAPSCREW - M12 X 1.75 X 35 | 19 | ||||
| ? | EL9093 | BRACKET | 4 | ||||
| ? | C1616 | CAPSCREW - 1/2" - 13NC X 2" | 24 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 24 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 24 | ||||
| ? | 58E-54-13870 | BRACKET | 2 | ||||
| ? | EM2229 | PAD | 4 | ||||
| ? | 58E-54-13860 | PAD | 2 | ||||
| ? | 58F-54-03920 | BRACKET | 6 | ||||
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 1 | ||||
| ? | 58F-54-40820 | TUBE | 1 | ||||
| ? | 58B-54-50350 | TUBE | 1 | ||||
| ? | 58F-54-03900 | PLATE, BENT | 1 | ||||
| ? | 58F-54-03910 | PLATE, BENT | 1 | ||||
| ? | MM0621 | CAPSCREW - M12 X 1.75 X 45 | 2 |
