| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-06-11020 | CABLE - 71J | 1 | ||||
| ? | 58F-06-11030 | CABLE - 74D | 1 | ||||
| ? | CH2260 | CABLE - 7M1A1 | 1 | ||||
| ? | CH2263 | CABLE - 7M1B2 | 1 | ||||
| ? | CH2264 | CABLE - 7M1C1 | 1 | ||||
| ? | CH2266 | CABLE - 7M2A1 | 1 | ||||
| ? | CH2269 | CABLE - 7M2B2 | 1 | ||||
| ? | CH2270 | CABLE - 7M2C1 | 1 | ||||
| ? | CH2261 | CABLE - 7M1A2 | 1 | ||||
| ? | CH2262 | CABLE - 7M1B1 | 1 | ||||
| ? | CH2265 | CABLE - 7M1C2 | 1 | ||||
| ? | CH2267 | CABLE - 7M2A2 | 1 | ||||
| ? | CH2268 | CABLE - 7M2B1 | 1 | ||||
| ? | CH2271 | CABLE - 7M2C2 | 1 | ||||
| ? | TV1918 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 12 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 20 | ||||
| ? | VC7836 | FLAT WASHER - 1/2" | 30 | ||||
| ? | TR6643 | NUT - 1/2" - 13NC | 12 | ||||
| ? | EM6779 | O-RING, METAL CLAD - 1 1/4" | 2 | ||||
| ? | EM8107 | O-RING, METAL CLAD - 1 1/2" | 12 | ||||
| ? | 58F-06-03470 | CABLE, GROUND | 1 | ||||
| ? | TD0794 | CAPSCREW - 5/16" - 18NC X 3/4" | 2 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 2 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 2 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | EL0364 | SOFTWARE, AC DRIVE | 1 |
