| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA5025 | PLATE & SHAFT, LH STAIR | 1 | ||||
| ? | XA5034 | BEARING | 1 | ||||
| ? | XA5043 | ZERK, GREASE | 1 | ||||
| ? | XA5035 | KEY, SHAFT - LH | 1 | ||||
| ? | XA5036 | KEY, SHAFT - RH | 1 | ||||
| ? | XA5031 | COUPLING, DRIVE | 1 | ||||
| ? | H8711 | SETSCREW - 1/4" - 20NC X 1/4" | 1 | ||||
| ? | XA5658 | SCREW, ALLEN HEAD - 3/8" - 16NC X 1" | 2 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | XA5030 | COUPLING, ACTUATOR | 1 | ||||
| ? | D1561 | SETSCREW - 1/4" - 20NC X 1/2" | 1 | ||||
| ? | XA5656 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 12 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 12 | ||||
| ? | XA5032 | ACTUATOR, ROTARY | 1 | ||||
| ? | XA5654 | FITTING, ELBOW - 90 DEG | 2 | ||||
| ? | XA5033 | SLEEVE, SPACER | 1 | ||||
| ? | XA5023 | PLATE & SHAFT, RH STAIR | 1 | ||||
| ? | 58F-06-11170 | SWITCH, LIMIT | 1 | ||||
| ? | MM0582 | CAPSCREW - M6 X 1.00 X 20 | 2 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 2 | ||||
| ? | XA5655 | FLAT WASHER - 1/4" | 2 | ||||
| ? | 58F-06-11160 | PLATE, LIMIT STRIKER | 1 | ||||
| ? | 58F-06-11150 | SCREW, ALLEN HEAD - 3/8" - 16NC X 1 1/2" | 2 | ||||
| ? | 58F-06-11140 | HARNESS, LIMIT SWITCH | 1 |
