| Наименование | Страница | Код страницы |
|---|---|---|
| RADIATOR & SHROUD ASSEMBLY 58C-03-10000 | 058 | 63307 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58C-03-10000 | RADIATOR & SHROUD ASSEMBLY (SEE INDEX) | 1 | 63307 | |||
| ? | VN9106 | CAPSCREW - 1 1/4" - 7NC X 3" | 4 | ||||
| ? | WA0366 | FLAT WASHER - 1 1/4" (HARDENED) | 4 | ||||
| ? | EH8107 | BRACKET - RH | 1 | ||||
| ? | EH8108 | BRACKET - LH | 1 | ||||
| ? | C1667 | CAPSCREW - 1" - 8NC X 2 1/2" | 2 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC | 2 | ||||
| ? | EL7455 | BAR, STABILIZER | 2 | ||||
| ? | MM0029 | CAPSCREW - M16 X 2.00 X 30 | 8 | ||||
| ? | MM0706 | FLAT WASHER - M16 (HARDENED) | 8 | ||||
| ? | E3909 | CAPSCREW - 1" - 8NC X 3 1/4" | 2 | ||||
| ? | PB6831 | ROD END | 2 | ||||
| ? | C1532 | NUT (SPECIAL) | 6 | ||||
| ? | PC0780 | MOUNT, RUBBER - TWO PIECE | 2 | ||||
| ? | ED9895 | WASHER (SPECIAL) | 4 | ||||
| ? | EF3378 | ROD, THREADED | 2 | ||||
| ? | MM0475 | LOCKWASHER - M20 | 8 | ||||
| ? | MM0091 | CAPSCREW - M20 X 2.50 X 80 | 8 | ||||
| ? | 01643-32060 | FLAT WASHER - M20 (HARDENED) | 16 | ||||
| ? | MM0182 | NUT - M20 X 2.50 | 8 |
