Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PC2558 |
AIR CLEANER ASSEMBLY (SEE INDEX) |
2 |
|
42766 |
|
|
? |
TB1406 |
GUARD, RAIN - FRONT |
2 |
|
|
|
|
? |
TB1018 |
GUARD, RAIN - R.H. |
2 |
|
|
|
|
? |
TB1019 |
GUARD, RAIN - L.H. |
2 |
|
|
|
|
? |
C1641 |
CAPSCREW - 5/8" - 11NC X 4 1/2" |
26 |
|
|
|
|
? |
WA0361 |
FLAT WASHER - 5/8" (HARDENED) |
26 |
|
|
|
|
? |
TR2961 |
CAPSCREW - 5/8" - 11NC X 1" |
8 |
|
|
|
|
? |
TR9082 |
FLAT WASHER - 5/8" |
8 |
|
|
|
|
? |
VC1390 |
LOCKWASHER - 5/8" |
8 |
|
|
|
|
? |
EH2861 |
TUBE, OUTER REAR - R.H. |
1 |
|
|
|
|
? |
EH2858 |
TUBE, OUTER FRONT - R.H. |
1 |
|
|
|
|
? |
EH4477 |
TUBE, INNER REAR - R.H. |
1 |
|
|
|
|
? |
EH4479 |
TUBE, INNER FRONT - R.H. |
1 |
|
|
|
|
? |
VW7882 |
HOSE, HUMP |
2 |
|
|
|
|
? |
WB1177 |
CLAMP, T-BOLT |
24 |
|
|
|
|
? |
WB1170 |
CLAMP, T-BOLT |
8 |
|
|
|
|
? |
WB1144 |
ELBOW, REDUCING - 36 DEG |
2 |
|
|
|
|
? |
WB1169 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
PB2484 |
ELBOW - 45 DEG |
2 |
|
|
|
|
? |
EH4483 |
TUBE, INNER FRONT - L.H. |
1 |
|
|
|
|
? |
EH4481 |
TUBE, INNER REAR - L.H. |
1 |
|
|
|
|
? |
EH2864 |
TUBE, OUTER FRONT - L.H. |
1 |
|
|
|
|
? |
EH2867 |
TUBE, OUTER REAR - L.H. |
1 |
|
|
|
|
? |
TX6040 |
ELBOW - 45 DEG |
2 |
|
|
|
|
? |
WB1179 |
CLAMP, T-BOLT |
8 |
|
|
|
|
? |
EJ9919 |
BRACKET, LONG |
2 |
|
|
|
|
? |
EJ9920 |
BRACKET, SHORT |
2 |
|
|
|
|
? |
MM0617 |
CAPSCREW - M12 X 1.75 X 25 |
8 |
|
|
|
|
? |
MM0462 |
FLAT WASHER - M12 |
8 |
|
|
|
|
? |
MM0472 |
LOCKWASHER - M12 |
8 |
|
|
|
|
? |
EJ9916 |
ROD, THREADED |
1 |
|
|
|
|
? |
EJ9917 |
ROD, THREADED |
1 |
|
|
|
|
? |
PC1247 |
ROD END, FEMALE |
26 |
|
|
|
|
? |
TL8151 |
JAM NUT - 1/2" - 20NF |
26 |
|
|
|
|
? |
WA0471 |
CAPSCREW - 1/2" - 13NC X 2 1/4" |
24 |
|
|
|
|
? |
WA4728 |
FLAT WASHER - 1/2" (HARDENED) |
52 |
|
|
|
|
? |
DF3500 |
LOCKNUT - 1/2" - 13NC |
26 |
|
|
|
|
? |
EJ9909 |
CLAMP |
13 |
|
|
|
|
? |
EJ9915 |
ROD, THREADED |
1 |
|
|
|
|
? |
EJ9910 |
ROD, THREADED |
5 |
|
|
|
|
? |
EJ9914 |
ROD, THREADED |
1 |
|
|
|
|
? |
TA6490 |
CLAMP ASSEMBLY |
2 |
|
|
|
|
? |
TA6483 |
• CLAMP |
2 |
|
|
|
|
? |
TA6491 |
• U-BOLT - 3/8" - 16NC |
2 |
|
|
|
|
? |
C0312 |
• LOCKWASHER - 3/8" |
4 |
|
|
|
|
? |
C1521 |
• NUT - 3/8" - 16NC |
4 |
|
|
|
|
? |
EJ2439 |
BAR |
1 |
|
|
|
|
? |
EJ9913 |
ROD, THREADED |
1 |
|
|
|
|
? |
EJ9912 |
ROD, THREADED |
1 |
|
|
|
|
? |
EJ9911 |
ROD, THREADED |
2 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1 1/2" |
2 |
|
|
|
|
? |
MM0606 |
CAPSCREW - M10 X 1.50 X 30 |
2 |
|
|
|
|
? |
MM0713 |
FLAT WASHER - M10 (HARDENED) |
2 |
|
|
|
|
? |
EJ9918 |
ANGLE |
1 |
|
|
|
|
? |
EG7576 |
CLAMP, DOUBLE |
2 |
|
|
|
|
? |
TD0792 |
CAPSCREW - 3/8" - 16NC X 2 1/4" |
3 |
|
|
|
|
? |
WA4726 |
FLAT WASHER - 3/8" (HARDENED) |
3 |
|
|
|
|
? |
HE5611 |
LOCKNUT - 3/8" - 16NC |
3 |
|
|
|
|
? |
PC1115 |
HOSE, DOUBLE HUMP |
4 |
|
|
|
