Номер на схеме	Каталожный номер	Название	Количество
?	PC1345	FUSE BLOCK	4
?	SD5390	MACHINE SCREW - #10 - 32NC X 1"	16
?	VC5344	FLAT WASHER - #10	16
?	DC3101	LOCKWASHER - #10	16
?	WB2941	NAME PLATE - FUSE BLOCK #1	1
?	WB2942	NAME PLATE - FUSE BLOCK #2	1
?	EK2512	NAME PLATE - FUSE BLOCK #3	1
?	EK2513	NAME PLATE - FUSE BLOCK #4	1
?	PC2399	FUSE - 1 AMP	1
?	08041-00500	FUSE - 5 AMP	9
?	08041-01000	FUSE - 10 AMP	18
?	08041-01500	FUSE - 15 AMP	14
?	08041-02000	FUSE - 20 AMP	13
?	EK2075	NAME PLATE - FS1 - FS12 CIR 712	1
?	WB3504	NAME PLATE - FS13 - FS16 11B1	1
?	EK2502	NAME PLATE - FS17 - FS24 CIR 11S	1
?	EK2503	NAME PLATE - FS1 - FS12 CIR 11	1
?	WB3313	NAME PLATE - FS13 - FS16	1
?	EL7626	NAME PLATE - FS17 - FS24 CIR 11GL	1
?	EK2505	NAME PLATE - FS1 - FS12 CIR 71	1
?	EK2508	NAME PLATE - FS13 - FS16 CIR 15SPD	1
?	EK2509	NAME PLATE - FS17 - FS24 CIR 12V	1
?	EK2510	NAME PLATE - FS1 - FS12 CIR 71CK	1
?	EK2501	NAME PLATE - FS13 -FS16	1
?	EK2511	NAME PLATE - FS17 - FS24 CIR 15VD1	1
?	WB3468	NAME PLATE - FH #1	1
?	WB3469	NAME PLATE - FH #2	1
?	WB3477	NAME PLATE - FH #3	1
?	WB3478	NAME PLATE - FH #4	1
?	PC0254	SWITCH, ROCKER (LOCKED)	1
?	WB2200	NAME PLATE - DLS	1
?	EM8242	HARNESS, AUXILIARY CONTROL CABINET INTERNAL	1
?	EF6927	• RESISTOR (22,100 OHM)	1
?	TS0299	• RESISTOR (2,000 OHM, 2W)	1
?	PC2399	• FUSE - 1 AMP	4
?	MM0459	FLAT WASHER - M6	4
?	MM0379	LOCKWASHER - M5 (EXTERNAL TOOTH)	4
?	MM0373	NUT - M5 X .8	4
?	EM8241	LABEL, FUSE BLOCK	1
