| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (HID) | 340 | 42268 |
| LIGHT ASSEMBLY (HID) | 340 | 42268 |
| LIGHT ASSEMBLY (HID) | 340 | 42268 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC2618 | HEADLIGHT ASSEMBLY - LOW BEAM (SEE FIG 42268) | 4 | 42268 | |||
| ? | PC2617 | HEADLIGHT ASSEMBLY - HIGH BEAM (SEE FIG 42268) | 4 | 42268 | |||
| ? | WB3524 | SCREW, HEX HEAD - #12 - 14NC X 3/4" | 40 | ||||
| ? | XB3256 | HARNESS, GRILLE - L.H. | 1 | ||||
| ? | XB3257 | HARNESS, GRILLE - R.H. | 1 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 12 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 28 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 28 | ||||
| ? | PC2619 | FOG LIGHT ASSEMBLY (SEE FIG 42268) | 2 | 42268 | |||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 18 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 4 | ||||
| ? | VL3932 | GROMMET | 2 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 28 |
