| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | GE0865 | CAPACITOR SUB-ASSEMBLY | 1 | ||||
| ? | GE0514 | • CAPACITOR | 1 | ||||
| ? | GE1175 | • CLAMP | 1 | ||||
| ? | GE1176 | • SUPPORT | 1 | ||||
| ? | VE4343 | FLAT WASHER - 5/16" | |||||
| ? | GE1383 | FLAT WASHER - 11/16" | |||||
| ? | VE4696 | LOCKWASHER - 5/16" | |||||
| ? | VE5013 | NUT - 5/16" - 18NC | |||||
| ? | GE0755 | POWER SUPPLY | 1 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | |||||
| ? | DC3584 | LOCKWASHER - 1/4" | |||||
| ? | TD1549 | NUT - 1/4" - 20NC | |||||
| ? | GE0231 | PANEL, FUSE | 1 | ||||
| ? | GE0232 | FUSE LIMITER | 1 | ||||
| ? | BF3908 | SHIELD | 1 | ||||
| ? | GE0170 | SENSOR, AC-DC | 2 | ||||
| ? | VE4655 | FLAT WASHER - #10 | |||||
| ? | VE4601 | LOCKWASHER - #10 | |||||
| ? | SF2755 | NUT - #10 - 32NF | |||||
| ? | TV3461 | CAPSCREW - 3/8" - 16NC X 5/8" | 2 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | |||||
| ? | VE4515 | FLAT WASHER - 3/8" | |||||
| ? | XA3591 | SHIELD | 1 | ||||
| ? | XA3592 | INSULATOR | 2 | ||||
| ? | GE0831 | CAPSCREW - 3/8" - 16NC X 3/8" | 1 | ||||
| ? | XA2784 | WASHER | 6 | ||||
| ? | 58B-43-00360 | DOOR PROP ASSEMBLY | 1 | ||||
| ? | 58B-43-00350 | SHIELD, HV CABLE | 1 | ||||
| ? | 58B-43-00280 | LOCKNUT - 3/8" - 16NC | 4 |
