| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB1109 | CLAMP, CABLE | 42 | ||||
| ? | EC1090 | STUD, THREADED - M16 X 2.00 | 30 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 36 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 36 | ||||
| ? | MM0181 | NUT - M16 X 2.00 | 36 | ||||
| ? | EK4014 | STUD, THREADED - M16 X 2.00 | 6 | ||||
| ? | EL7421 | MOUNT, CLAMP | 1 | ||||
| ? | KC7221 | CAPSCREW - 5/8" - 11NC X 8 1/2" | 2 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 2 | ||||
| ? | TR9082 | FLAT WASHER - 5/8" | 2 |
