| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING CYLINDER ASSEMBLY EM0241 | 558 | 60018 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB1145 | CAPSCREW - 1" - 8NC X 11" (1) | 4 | ||||
| ? | EH4367 | PIN (1) | 4 | ||||
| ? | EK2849 | SEAL, BEARING (1) | 8 | ||||
| ? | EJ8353 | SPACER (1) | 8 | ||||
| ? | PC1686 | BEARING, SPHERICAL (1) | 4 | ||||
| ? | EM0241 | STEERING CYLINDER ASSEMBLY (SEE INDEX) | 2 | 60018 | |||
| ? | EK1030 | RETAINER, ANTI-ROTATION (1) | 4 | ||||
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 32 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 32 | ||||
| ? | EH4369 | WASHER (1) | 4 | ||||
| ? | TY2239 | RETAINER (1) | 4 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC (1) | 4 | ||||
| ? | AK5098 | NOTE: (1) INCLUDED IN AK5098 STEERING CYLINDER | |||||
| ? | AND TIE ROD PIN KIT. |
