| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | GE0128 | COLLAR (INNER) | 1 | ||||
| ? | GE0127 | BEARING | 1 | ||||
| ? | GE0126 | COLLAR (OUTER) | 1 | ||||
| ? | GE0125 | CAP, BEARING | 1 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" | 8 | ||||
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 8 | ||||
| ? | GE0124 | FRAME, HEAD | 1 | ||||
| ? | VE5762 | FLAT WASHER - 5/16" | 2 | ||||
| ? | GE0628 | CAPSCREW - 5/16" - 18NC X 2 1/4" | 2 | ||||
| ? | XA4257 | LOCTITE | |||||
| ? | VE3027 | FLAT WASHER - 3/8" | 27 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 14 | ||||
| ? | VE7206 | TAPE, GLASS - .014 | 1 | ||||
| ? | GE0112 | RING, BUS (TC) | 1 | ||||
| ? | VE4515 | FLAT WASHER - 3/8" | |||||
| ? | VE4641 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 3 | ||||
| ? | GE0137 | CLAMP | 1 | ||||
| ? | GE1367 | CONNECTION, STRAP | 3 | ||||
| ? | VE4701 | CAPSCREW - 3/8" - 16NC X 3" | 2 | ||||
| ? | VE7272 | SEALANT | |||||
| ? | GE0136 | BLOCK | 1 | ||||
| ? | VE4783 | PUTTY | |||||
| ? | VE4334 | TAPE | |||||
| ? | VE4335 | TAPE | |||||
| ? | VE4640 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 4 | ||||
| ? | VE4739 | CAPSCREW - 3/8" - 16NC X 1" | 8 | ||||
| ? | XA4136 | FLAT WASHER - 5/8" (HARDENED) | |||||
| ? | XA4217 | CAPSCREW - 5/8" - 11NC X 2" | |||||
| ? | VE4687 | LOCKWASHER - 3/8" | 5 | ||||
| ? | GE0113 | RING, BUS (TB) | 1 | ||||
| ? | GE0114 | RING, BUS (TA) | 1 | ||||
| ? | GE0115 | RING, BUS (N) | 1 | ||||
| ? | GE0394 | DEFLECTOR, AIR | 1 | ||||
| ? | GE0122 | WEIGHT, BALANCING | |||||
| ? | XA4256 | SENSOR, SPEED | 1 | ||||
| ? | GE0119 | WHEEL, SENSOR | 1 | ||||
| ? | GE0120 | NUT | 1 | ||||
| ? | GE0123 | LOCKWASHER | 1 | ||||
| ? | VE4516 | FLAT WASHER - 3/8" | 8 | ||||
| ? | VE4526 | CAPSCREW - 3/8" - 16NC X 7/8" | 18 | ||||
| ? | XA4258 | STATOR ASSEMBLY | 1 | ||||
| ? | GE1252 | STATOR REWIND KIT | 1 |
