Содержание Dump Trucks Komatsu AFE59-EM 930E-4 S/N A31352 LAS PELAMBRES(AFE59-EM)
MOTOR ASSEMBLY - WHEEL 1/2 XA4259(688 : 64254)
Номер на схеме Каталожный номер Название Количество Детали
? GE0128 COLLAR (INNER) 1
? GE0127 BEARING 1
? GE0126 COLLAR (OUTER) 1
? GE0125 CAP, BEARING 1
? VE5185 FLAT WASHER - 1/2" 8
? VE4518 CAPSCREW - 1/2" - 13NC X 1 1/2" 8
? GE0124 FRAME, HEAD 1
? VE5762 FLAT WASHER - 5/16" 2
? GE0628 CAPSCREW - 5/16" - 18NC X 2 1/4" 2
? XA4257 LOCTITE
? VE3027 FLAT WASHER - 3/8" 27
? TC1233 NUT - 3/8" - 16NC 14
? VE7206 TAPE, GLASS - .014 1
? GE0112 RING, BUS (TC) 1
? VE4515 FLAT WASHER - 3/8"
? VE4641 CAPSCREW - 3/8" - 16NC X 1 1/4" 3
? GE0137 CLAMP 1
? GE1367 CONNECTION, STRAP 3
? VE4701 CAPSCREW - 3/8" - 16NC X 3" 2
? VE7272 SEALANT
? GE0136 BLOCK 1
? VE4783 PUTTY
? VE4334 TAPE
? VE4335 TAPE
? VE4640 CAPSCREW - 3/8" - 16NC X 1 1/2" 4
? VE4739 CAPSCREW - 3/8" - 16NC X 1" 8
? XA4136 FLAT WASHER - 5/8" (HARDENED)
? XA4217 CAPSCREW - 5/8" - 11NC X 2"
? VE4687 LOCKWASHER - 3/8" 5
? GE0113 RING, BUS (TB) 1
? GE0114 RING, BUS (TA) 1
? GE0115 RING, BUS (N) 1
? GE0394 DEFLECTOR, AIR 1
? GE0122 WEIGHT, BALANCING
? XA4256 SENSOR, SPEED 1
? GE0119 WHEEL, SENSOR 1
? GE0120 NUT 1
? GE0123 LOCKWASHER 1
? VE4516 FLAT WASHER - 3/8" 8
? VE4526 CAPSCREW - 3/8" - 16NC X 7/8" 18
? XA4258 STATOR ASSEMBLY 1
? GE1252 STATOR REWIND KIT 1
