| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 4 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" | 4 | ||||
| ? | XA3158 | COVER | 1 | ||||
| ? | XA5878 | CABLE ASSEMBLY - T1 | 2 | ||||
| ? | XA5879 | CABLE ASSEMBLY - T2 | 2 | ||||
| ? | XA5880 | CABLE ASSEMBLY - T3 | 2 | ||||
| ? | VE4626 | NUT - 5/16" - 18NC | 3 | ||||
| ? | VE4648 | FLAT WASHER - 5/16" | 6 | ||||
| ? | XA3154 | TERMINAL | 3 | ||||
| ? | VE4625 | CAPSCREW - 5/16" - 18NC X 1 1/4" | 3 | ||||
| ? | VE1640 | SPACER | 1 | ||||
| ? | XA3153 | CLAMP | 1 | ||||
| ? | VE1641 | PLATE, CLAMP | 1 | ||||
| ? | VE5002 | CAPSCREW - 5/16" - 18NC X 1 3/4" | 2 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 2 | ||||
| ? | XA4218 | CAPSCREW - 3/8" - 16NC X 3 3/4" | 6 | ||||
| ? | VE3027 | FLAT WASHER - 3/8" | 9 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 3 | ||||
| ? | VJ0970 | INSULATOR | 3 | ||||
| ? | VS6813 | STUD | 3 | ||||
| ? | XA5877 | GLASTIC CHANNEL | 1 | ||||
| ? | VE4752 | CEMENT | |||||
| ? | VE3916 | PUTTY, AIR DRY |
