Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
GE0152 |
RESISTOR PANEL |
1 |
|
|
|
|
? |
VJ9059 |
• RESISTOR |
2 |
|
|
|
|
? |
PB2685 |
• CONTACT CLIP ASSEMBLY |
2 |
|
|
|
|
? |
GE0861 |
GROMMET |
3 |
|
|
|
|
? |
PB6137 |
CONTACTOR ASSEMBLY |
1 |
|
|
|
|
? |
VE3530 |
• INTERLOCK, POSITION SENSOR (SEE INDEX) |
1 |
|
64035 |
|
|
? |
VE1317 |
• CONTACTOR - GF & GFR (SEE INDEX) |
1 |
|
64069 |
|
|
? |
GE1843 |
CONTACTOR ASSEMBLY - R.P. (SEE INDEX) |
2 |
|
64401 |
|
|
? |
VE4687 |
LOCKWASHER - 3/8" |
|
|
|
|
|
? |
VE4515 |
FLAT WASHER - 3/8" |
|
|
|
|
|
? |
TC1233 |
NUT - 3/8" - 16NC |
|
|
|
|
|
? |
PB5230 |
RESISTOR, THYRITE |
1 |
|
|
|
|
? |
VE4343 |
FLAT WASHER - 5/16" |
|
|
|
|
|
? |
VE4696 |
LOCKWASHER - 5/16" |
|
|
|
|
|
? |
VE5013 |
NUT - 5/16" - 18NC |
|
|
|
|
|
? |
GE0857 |
PANEL ASSEMBLY |
1 |
|
|
|
|
? |
SP8417 |
FLAT WASHER - 1/4" |
|
|
|
|
|
? |
DC3584 |
LOCKWASHER - 1/4" |
|
|
|
|
|
? |
TD1549 |
NUT - 1/4" - 20NC |
|
|
|
|
|
? |
PB3348 |
INSULATOR |
4 |
|
|
|
|
? |
XA3143 |
STUD |
4 |
|
|
|
|
? |
GE0177 |
BOARD, PRINTED WIRE |
1 |
|
|
|
|
? |
PB3606 |
SPACER |
8 |
|
|
|
|
? |
XA3129 |
CAP, LENS |
2 |
|
|
|
|
? |
VE4601 |
LOCKWASHER - #10 |
|
|
|
|
|
? |
SF2755 |
NUT - #10 - 32NF |
|
|
|
|
|
? |
VE4600 |
FLAT WASHER - #10 |
|
|
|
|
|
? |
BF4452 |
MODULE, SUPPRESSION |
6 |
|
|
|
|
? |
VE4921 |
CAPSCREW - #10 - 32NF X 1" |
8 |
|
|
|
|
? |
VE4655 |
FLAT WASHER - #10 |
|
|
|
|
|
? |
GE0219 |
SUPPORT, MODULE |
2 |
|
|
|
|
? |
GE0220 |
SUPPORT, MODULE |
2 |
|
|
|
|
? |
VJ6457 |
SHIELD |
1 |
|
|
|
|
? |
VJ6456 |
SHIELD |
1 |
|
|
|
|
? |
VG7043 |
RELAY - CPR & GFR (SEE INDEX) |
1 |
|
64037 |
|
|
? |
VE7237 |
CAPSCREW - 1/4" - 20NC |
4 |
|
|
|
|
? |
VE7202 |
WASHER - 1/4" (SPECIAL) |
4 |
|
|
|
|
? |
VJ6455 |
BASE |
1 |
|
|
|
|
? |
BF4223 |
BOLT, INSULATED |
1 |
|
|
|
|
? |
BF3904 |
INSULATION |
2 |
|
|
|
|
? |
VE4640 |
CAPSCREW - 3/8" - 16NC X 1 1/2" |
|
|
|
|
|
? |
GE1397 |
BUS, BAR |
2 |
|
|
|
|
? |
GE1416 |
GROMMET |
1 |
|
|
|
|
? |
58B-43-00260 |
GROMMET - 2" O.D. |
1 |
|
|
|
|
? |
GE0594 |
BUSHING |
1 |
|
|
|
|
? |
GE1395 |
BUS BAR |
1 |
|
|
|
|
? |
VE4699 |
LOCKWASHER - 1/2" |
2 |
|
|
|
|
? |
VE4698 |
NUT - 1/2" - 13NC |
2 |
|
|
|
|
? |
VE4519 |
FLAT WASHER - 1/2" |
2 |
|
|
|
|
? |
VE4687 |
LOCKWASHER - 3/8" |
4 |
|
|
|
|
? |
VE4516 |
FLAT WASHER - 3/8" |
4 |
|
|
|
|
? |
GE1420 |
CAPSCREW |
4 |
|
|
|
|
? |
GE0579 |
STUD |
1 |
|
|
|
|
? |
VE4500 |
CAPSCREW - 3/8" - 16NC X 1 3/4" |
1 |
|
|
|
|
? |
58B-43-00211 |
BOARD, TERMINAL |
1 |
|
|
|
