Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	EG6269	HOSE	4
?	WB1088	CLAMP, T-BOLT	16
?	EH3376	TUBE	1
?	EH3382	BRACKET	2
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	6
?	TC1231	LOCKWASHER - 3/8"	14
?	TR4436	FLAT WASHER - 3/8"	6
?	WA5460	CLAMP, TUBE	2
?	C5771	PLUG, PIPE - 1/2"	3
?	EL0049	TUBE	2
?	EG6540	GASKET	2
?	C1603	CAPSCREW - 3/8" - 16NC X 1 1/4"	8
?	TF6957	DRAIN COCK	1
?	E2579	NIPPLE, CLOSE	1
?	EH3377	TUBE	1
?	EH3387	TUBE	1
?	EL2032	TUBE	1
?	EH3195	SHEET, BENT	2
?	EL0668	BRACKET	2
?	EL2027	PLATE, BENT	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	6
?	MM0713	FLAT WASHER - M10 (HARDENED)	10
?	EL2034	PLATE, BENT	1
?	EL2033	PLATE, BENT	1
?	MM0607	CAPSCREW - M10 X 1.50 X 35	2
?	MM0719	NUT - M10 X 1.50	2
