| Наименование | Страница | Код страницы |
|---|---|---|
| RETRACTABLE LADDER ASSEMBLY 1/2 58F-60-01210 | 646 | 62132 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 2 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 2 | ||||
| ? | MM0714 | FLAT WASHER - M12 (HARDENED) | 2 | ||||
| ? | MM0694 | LOCKNUT - M12 X 1.75 | 2 | ||||
| ? | EC6173 | CLAMP | 2 | ||||
| ? | XB5202 | HANDRAIL | 1 | ||||
| ? | MM0093 | CAPSCREW - M16 X 2.00 X 70 | 4 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 4 | ||||
| ? | XB5196 | SPACER | 4 | ||||
| ? | 58F-60-01210 | LADDER ASSEMBLY, RETRACTABLE (SEE INDEX) | 1 | 62132 | |||
| ? | MM0044 | CAPSCREW - M16 X 2.00 X 40 | 2 | ||||
| ? | MM0706 | FLAT WASHER - M16 (HARDENED) | 2 | ||||
| ? | MM0696 | LOCKNUT - M16 X 2.00 | 2 | ||||
| ? | XB5198 | PLATFORM | 1 | ||||
| ? | XB4034 | PLATE, BENT | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 | ||||
| ? | MM0713 | FLAT WASHER - M10 (HARDENED) | 4 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 4 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 |
