| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TANK, OIL RESERVE (1) | 1 | |||||
| ? | XA0003 | VALVE, AIR RELIEF | 1 | ||||
| ? | BF3351 | CAP, FILLER | 1 | ||||
| ? | 58E-61-00090 | SWITCH, FLOAT | 1 | ||||
| ? | BF3352 | GLASS, SIGHT | 4 | ||||
| ? | 58E-61-00080 | VALVE, FILL | 1 | ||||
| ? | XA0002 | SCREEN, IN-LINE | 1 | ||||
| ? | 58E-61-00010 | PUMP | 1 | ||||
| ? | XA1896 | SCREEN, TANK | 1 | ||||
| ? | CABLES, ELECTRICAL | 3 | |||||
| ? | 58E-60-11030 | AUTOMATIC FILL CONTROL (AFC) BOX | 1 | ||||
| ? | XA3903 | • BOX | 1 | ||||
| ? | XA2344 | • RELAY | 1 | ||||
| ? | XA3905 | • BLOCK, TERMINAL | 1 | ||||
| ? | XA3904 | • HARNESS, PANEL | 1 | ||||
| ? | XA2345 | • SWITCH, POWER | 1 | ||||
| ? | XA2342 | • SWITCH, START | 1 | ||||
| ? | BF5021 | • LIGHT, LED - AMBER (24 VDC) | 1 | ||||
| ? | BF5022 | • LIGHT, LED - RED (24 VDC) | 1 | ||||
| ? | VZ3046 | • CORD GRIP | 3 | ||||
| ? | XA3906 | • LABEL, FRONT COVER | 1 | ||||
| ? | 58E-03-01050 | HOSE | 2 | ||||
| ? | 58E-03-01060 | HOSE | 1 | ||||
| ? | 58E-03-01040 | HOSE | 1 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. |
