| Наименование | Страница | Код страницы |
|---|---|---|
| WIPER LINKAGE ASSEMBLY PB9926 | 260 | 42777 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB9923 | MOTOR, WIPER - 24 VOLT | 1 | ||||
| ? | MM0592 | CAPSCREW - M8 X 1.25 X 16 | 5 | ||||
| ? | MM0712 | FLAT WASHER - M8 (HARDENED) | 14 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 5 | ||||
| ? | SM4345 | PLATE | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 3 | ||||
| ? | MM0711 | FLAT WASHER - M6 (HARDENED) | 3 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 3 | ||||
| ? | PB9926 | WIPER LINKAGE ASSEMBLY (SEE INDEX) | 1 | 42777 | |||
| ? | PC1823 | ARM, WET WIPER | 2 | ||||
| ? | XA2095 | NOZZLE | 2 | ||||
| ? | PB9925 | BLADE, WIPER | 2 | ||||
| ? | MM0022 | CAPSCREW - M8 X 1.25 X 20 | 4 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 4 | ||||
| ? | EG0735 | TEE, HOSE | 1 | ||||
| ? | TF6380 | GROMMET, RUBBER | 2 | ||||
| ? | SM4477 | HOSE | 2 | ||||
| ? | EG3904 | HOSE | 1 | ||||
| ? | NUT - M8 X 1.25 (1) | 1 | |||||
| ? | COVER (1) | 1 | |||||
| ? | NUT - M20 X 1.00 (1) | 1 | |||||
| ? | WASHER (1) | 1 | |||||
| ? | WASHER (1) | 1 | |||||
| ? | EM8721 | TUBE, HEAT SHRINK | 1 | ||||
| ? | EM8722 | TUBE, HEAT SHRINK | 1 | ||||
| ? | XA3071 | NOTE: (1) NOT SERVICED SEPARATELY. | |||||
| ? | ORDER XA3071 HARDWARE KIT. |
