| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | TM9278 | PROTECTOR | 1 | ||||
| ? | TZ8637 | PLUG, SENSOR PORT | 1 | ||||
| ? | TY8879 | PLUG, VENT (1) | 1 | ||||
| ? | VN9140 | CAPSCREW - 3/4" - 10NC X 4" | 48 | ||||
| ? | WA0362 | FLAT WASHER - 3/4" | 48 | ||||
| ? | R1073 | DRIVE SCREW - #6 X 3/16" | 8 | ||||
| ? | WA2892 | PLATE, DANGER | 2 | ||||
| ? | H2981 | BALL, STEEL - 3/4" (1) | 4 | ||||
| ? | VD5076 | GASKET (2) | 1 | ||||
| ? | EM0269 | HOUSING | 1 | ||||
| ? | WA1281 | RING, BACKUP (1) | 4 | ||||
| ? | PC0627 | SEAL, WIPER - 14" (1) | 1 | ||||
| ? | PC0625 | SEAL, ROD DOUBLE LIP - 14" (1) | 1 | ||||
| ? | PC0626 | SEAL, ROD BUFFER - 14" (1) | 1 | ||||
| ? | 58E-50-00040 | BEARING RETAINER, LOWER (LOWER) | 1 | ||||
| ? | WA0106 | O-RING (1) | 4 | ||||
| ? | VW4451 | NUT, WHEEL | 1 | ||||
| ? | VC2629 | PIN (1) | 1 | ||||
| ? | EH6529 | STOP, PISTON | 1 | ||||
| ? | EH6536 | KEY, SQUARE | 1 | ||||
| ? | 58E-50-00011 | BEARING RETAINER, UPPER (UPPER) | 1 | ||||
| ? | PC2871 | BEARING, UPPER | 1 | ||||
| ? | VN9096 | CAPSCREW - 7/8" - 9NC X 2 3/4" | 12 | ||||
| ? | WA0363 | FLAT WASHER - 7/8" | 12 | ||||
| ? | EH7326 | CAP, SUSPENSION | 1 | ||||
| ? | PC2880 | BEARING, LOWER | 1 | ||||
| ? | PB2194 | CHARGING VALVE (2) | 1 | ||||
| ? | TD7179 | • CORE, VALVE | 1 | ||||
| ? | TR9993 | • CAP, VALVE | 1 | ||||
| ? | TF1144 | • O-RING | 1 | ||||
| ? | WA0052 | • O-RING | 1 | ||||
| ? | 58E-50-00130 | PISTON ASSEMBLY | 1 | ||||
| ? | 58E-50-00140 | • PISTON | 1 | ||||
| ? | WA0439 | • O-RING (1) | 1 | ||||
| ? | WA1439 | • RING, BACKUP (1) | 1 | ||||
| ? | XB4388 | • PLUG, PISTON | 1 | ||||
| ? | XB4389 | • RING, RETAINER | 3 | ||||
| ? | XB4390 | • PLATE, RETAINER | 1 | ||||
| ? | VN9032 | • CAPSCREW - 1/2" - 13NC X 1" | 1 | ||||
| ? | WA0360 | • FLAT WASHER - 1/2" | 1 | ||||
| ? | VM0314 | • PLUG (1) | 1 | ||||
| ? | 58B-50-00900 | • BOSS | 4 | ||||
| ? | 58E-50-00400 | SPACER, CAP | 2 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | WA3925 | DECAL, HYDRAIR II | 1 | ||||
| ? | AK4063 | SUSPENSION OIL MIXTURE (5 GAL) | |||||
| ? | AK4064 | SUSPENSION OIL MIXTURE (55 GAL) | |||||
| ? | 58E-FS-AK010 | NOTE: (1) INCLUDED IN 58E-FS-AK010 SEAL KIT. | |||||
| ? | RK1887 | (2) INCLUDED IN RK1887 CHARGING VALVE REPAIR KIT. | |||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
