| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0178 | NUT - M10 X 1.50 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | 08193-20012 | CLIP | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 2 | ||||
| ? | MM0025 | CAPSCREW - M6 X 1.00 X 20 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0717 | NUT - M6 X 1.00 | 4 | ||||
| ? | 58F-06-03750 | BLOWER PRESSURE SWITCH ASSEMBLY (1) | 1 | ||||
| ? | EL9925 | • HARNESS | 1 | ||||
| ? | 58F-06-01860 | • PRESSURE SWITCH | 1 | ||||
| ? | TA0603 | FITTING, NYLON | 2 | ||||
| ? | TK7603 | TUBE, NYLON | 1 | ||||
| ? | XB0591 | HARNESS, BLOWER PRESSURE SWITCH | 1 | ||||
| ? | TC8757 | BUSHING, PIPE - 2.00 X 1.00 | 1 | ||||
| ? | NOTE: (1) NOT SERVICED AS AN ASSEMBLY. | ||||||
| ? | ORDER INDIVIDUAL COMPONENT PARTS. |
