| Наименование | Страница | Код страницы |
|---|---|---|
| HYDRAULIC FILTER - HOIST 58E-60-00901 | 502 | 63042 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA6250 | HOSE | 4 | ||||
| ? | EL8980 | PLATE | 1 | ||||
| ? | VC1387 | CAPSCREW - 1/2" - 13NC X 1" | 8 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 12 | ||||
| ? | VC6561 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 16 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 16 | ||||
| ? | TF3231 | CLAMP, SPLIT FLANGE - 2" | 8 | ||||
| ? | WA0187 | O-RING | 4 | ||||
| ? | PB8318 | ELBOW | 2 | ||||
| ? | 58E-60-00901 | HYDRAULIC FILTER (1) (SEE INDEX) | 1 | 63042 | |||
| ? | WA0471 | CAPSCREW - 1/2" - 13NC X 2 1/4" | 4 | ||||
| ? | PC2057 | WASHER, HEAD | 4 | ||||
| ? | WA2586 | MOUNT, RUBBER | 4 | ||||
| ? | PC2058 | WASHER, TAIL | 4 | ||||
| ? | TR6643 | NUT - 1/2" - 13NC | 4 | ||||
| ? | C1622 | CAPSCREW - 1/2" - 13NC X 3 1/2" | 4 | ||||
| ? | EM7998 | BLOCK, ADAPTER | 1 | ||||
| ? | VM0319 | PLUG | 1 | ||||
| ? | NOTE: (1) NOT SERVICED AS AN ASSEMBLY. | ||||||
| ? | ORDER INDIVIDUAL COMPONENT PARTS. |
