| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SM4274 | PLATE, SIDE - RH | 1 | ||||
| ? | PB9829 | CAPSCREW - M6 X 1.00 X 16 | 10 | ||||
| ? | 58F-80-00040 | SCREW, FLAT HEAD - #10 - 32NF X 5/8" | 8 | ||||
| ? | 58B-06-00110 | PANEL, DIAGNOSTIC INFORMATION DISPLAY (DID) | 1 | ||||
| ? | EM4640 | PLATE, BENT (DID PANEL MOUNTING) | 1 | ||||
| ? | 58E-06-07980 | PLATE, SIDE - LH | 1 | ||||
| ? | TR8279 | GROMMET | 2 | ||||
| ? | PB8334 | CLAMP, STRAIN RELIEF | 5 | ||||
| ? | VC8762 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 6 | ||||
| ? | TR4436 | FLAT WASHER, HARDENED - 3/8" | 6 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 6 | ||||
| ? | SM5049 | NUT, SPRING - 3/8" - 16NC | 6 | ||||
| ? | 58E-06-00605 | HARNESS, WIRING - ENGINE/CAB DIAGNOSTIC | 1 | ||||
| ? | WB1305 | CLAMP, CUSHIONED - 1 1/2" | 3 | ||||
| ? | WA4513 | SCREW - #10 - 24NC X 1/2" | 3 | ||||
| ? | DF3445 | FLAT WASHER - #12 | 3 | ||||
| ? | SG3146 | GROMMET | 1 | ||||
| ? | 58E-06-05201 | PLATE, DIAGNOSTIC | 1 | ||||
| ? | WB3115 | NAME PLATE - ENGINE DIAG 4 | 1 | ||||
| ? | MM0331 | MACHINE SCREW - M3 X 0.5 X 20 | 8 | ||||
| ? | MM0376 | LOCKWASHER, EXTERNAL TOOTH - M3 | 8 | ||||
| ? | MM0370 | NUT - M3 X 0.5 | 8 | ||||
| ? | WB3116 | NAME PLATE - DRIVE SYSTEM DIAG 1 | 1 | ||||
| ? | 58F-06-40830 | ADAPTER, RJ45 | 1 | ||||
| ? | PB8256 | SCREW LOCK, FEMALE | 6 | ||||
| ? | WB3120 | NAME PLATE - KOMTRAX PLUS DIAG 6 | 1 | ||||
| ? | WB3117 | NAME PLATE - INTERFACE DIAG 5 | 1 | ||||
| ? | 58E-06-80020 | NAME PLATE - PC DIAG 9 | 1 | ||||
| ? | WB3114 | NAME PLATE - ENGINE DIAG 2 | 1 | ||||
| ? | MM0345 | MACHINE SCREW - M4 X 0.7 X 8 | 4 | ||||
| ? | MM0378 | LOCKWASHER, EXTERNAL TOOTH - M4 | 4 | ||||
| ? | MM0372 | NUT - M4 X 0.7 | 4 | ||||
| ? | 58E-06-20370 | NAME PLATE - THIRD PARTY DIAG | 1 |
