Содержание Dump Trucks Komatsu AFE57-DZ 830E-1AC S/N A30561 - A30562 MT. THORLEY(AFE57-DZ)
FOOTREST AND FLOOR MATS(166 : 55651)
Номер на схеме Каталожный номер Название Количество Детали
? EK2782 FLOOR MAT, FRONT 1
? SM5435 FLOOR MAT, THRESHOLD 2
? EK2811 FLOOR MAT, REAR 1
? EK2817 FLOOR MAT, SEAT 1
? SM5048 FOOTREST 1
? 27705R1 SCREW, TAP - 1/4" - 14NC X 1" 4
? SM5434 FLOOR MAT, FOOTREST 1

Dump Trucks Komatsu / AFE57-DZ 830E-1AC S/N A30561 - A30562 MT. THORLEY(AFE57-DZ) / FOOTREST AND FLOOR MATS(166 : 55651)
?
?
?
?
?
?
?
?
