Номер на схеме	Каталожный номер	Название	Количество
?	XA3515	RADIATOR, AFTERCOOLER (LTC)	1
?	XA2836	• MEMBER, SIDE	1
?	XA2837	• MEMBER, SIDE	1
?	XA3532	• TANK, CENTER	1
?	XA3533	• TANK	1
?	XA3534	• TANK	1
?	XA3535	• SUPPORT, CENTER	2
?	C0312	• LOCKWASHER - 3/8"	8
?	C1602	• CAPSCREW - 3/8" - 16NC X 1"	8
?	C1540	• LOCKWASHER - 1/2"	20
?	VE3460	• CAPSCREW, HEX HEAD (HEAVY-DUTY)	20
?	XA2721	• SEAL, RUBBER LOCKING	512
?	XA2720	• SEAL, RUBBER	512
?	VE3475	• TUBE	276
?	BF0634	• TUBE ASSEMBLY	236
?	VE1219	• END, TUBE STAY	8
?	BF0819	• BAFFLE, BOTTOM	4
?	BF0818	• BAFFLE, TOP	4
?	XA3514	RADIATOR, JACKET WATER (HTC)	1
?	XA3528	• TANK	1
?	XA3529	• TANK, CENTER	1
?	XA3530	• TANK	1
?	XA2844	• MEMBER, SIDE	1
?	XA2845	• MEMBER, SIDE	1
?	XA3531	• SUPPORT, CENTER	2
?	C1528	• NUT - 3/4" - 16NF	12
?	VE1285	• BRACKET, X-BRACE	2
?	XA2721	• SEAL, RUBBER LOCKING	780
?	XA2720	• SEAL, RUBBER	780
?	VE7648	• BAFFLE, AIR	2
?	VE7649	• BAFFLE, AIR	2
?	C1540	• LOCKWASHER - 1/2"	20
?	VE3460	• CAPSCREW, HEX HEAD (HEAVY-DUTY)	20
?	C0312	• LOCKWASHER - 3/8"	8
?	C1602	• CAPSCREW - 3/8" - 16NC X 1"	8
?	XA2806	• FLAT WASHER - 5/16"	6
?	C5747	• CAPSCREW - 5/16" - 18NC X 3/4"	4
?	VE6312	• NUT, HEX HEAD	2
?	BF0634	• TUBE ASSEMBLY	476
?	VE3475	• TUBE	304
?	BF2772	• X-BRACE ROD	2
?	VE1219	• END, TUBE STAY	16
