| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC1375 | SWITCH, PUSH - PULL | 1 | ||||
| ? | WB3428 | PLATE, STARTER DISCONNECT | 1 | ||||
| ? | MM0341 | MACHINE SCREW - M4 X 0.7 X 10 | 14 | ||||
| ? | MM0378 | LOCKWASHER - M4 | 12 | ||||
| ? | WB3429 | PLATE, PROPEL DISCONNECT | 1 | ||||
| ? | PC2527 | LEVER, LOCKOUT | 1 | ||||
| ? | EC1725 | SWITCH | 2 | ||||
| ? | XB3622 | BUS BAR | 1 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 3 | ||||
| ? | WB3098 | CLAMP, CUSHION - 3/8" | 3 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 8 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 4 | ||||
| ? | XB5736 | BUS BAR | 1 | ||||
| ? | DF3500 | LOCKNUT - 1/2" - 13NC | 4 | ||||
| ? | VF5369 | JAM NUT - 1/2" - 13NC | 4 | ||||
| ? | XB5735 | BUS BAR | 2 | ||||
| ? | VN9773 | FLAT WASHER - 1/4" | 8 | ||||
| ? | PC2528 | SWITCH | 1 | ||||
| ? | TR1306 | CAPSCREW - 1/4" - 20NC X 1" | 8 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 4 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 4 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 4 | ||||
| ? | EK9945 | PLATE, BENT | 2 | ||||
| ? | WB3427 | PLATE, MASTER DISCONNECT | 1 | ||||
| ? | WB3432 | DECAL, PUSH BUTTON | 1 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 8 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 8 | ||||
| ? | XB5831 | HARNESS, ISOLATION BOX | 1 | ||||
| ? | PB4767 | • RELAY | 3 | ||||
| ? | 421-06-11970 | • DIODE - 3 AMP | 4 | ||||
| ? | EM6500 | • LED | 6 | ||||
| ? | VN7139 | SCREW - #10 - 24NC X 3/4" | 3 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 3 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 3 |
