Содержание Dump Trucks Komatsu AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN)
CAB LIGHTS(164 : 43399)
Номер на схеме Каталожный номер Название Количество Детали
? PB8205 LIGHT, BRAKE - RED 1
? PB8211 • LENS, RED 1
? VZ1912 • BULB 1
? PB8206 LIGHT, RETARD - AMBER 1
? PB8207 • LENS, AMBER 1
? VZ1912 • BULB 1
? WA5654 SCREW 3
? VE5837 LIGHT, DOME 1
? VE8635 • LENS, PLASTIC 1
? VE8636 • SWITCH 1
? VZ1912 • BULB 1
? TR1374 LOCKWASHER - 1/2" 2
? NOTE: NS = NOT SHOWN
? XB5532 TUBE, FLEX 2

Dump Trucks Komatsu / AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN) / CAB LIGHTS(164 : 43399)
?
?
?
?
?
?
