Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PC2558 |
AIR CLEANER ASSEMBLY (SEE INDEX) |
1 |
|
43406 |
|
|
? |
EJ9917 |
ROD, THREADED |
1 |
|
|
|
|
? |
EK1648 |
ROD, THREADED |
6 |
|
|
|
|
? |
EK1728 |
ROD, THREADED |
1 |
|
|
|
|
? |
WB1169 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
PC0858 |
ELBOW, REDUCING |
2 |
|
|
|
|
? |
WB1170 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
EJ2407 |
TUBE, INNER REAR - RH |
1 |
|
|
|
|
? |
WB1177 |
CLAMP, T-BOLT |
12 |
|
|
|
|
? |
PC1115 |
HOSE, DOUBLE HUMP |
2 |
|
|
|
|
? |
EG7576 |
CLAMP, DOUBLE |
4 |
|
|
|
|
? |
VC8762 |
CAPSCREW - 3/8" - 16NC X 1 1/2" |
3 |
|
|
|
|
? |
WA4726 |
FLAT WASHER - 3/8" |
6 |
|
|
|
|
? |
HE5611 |
LOCKNUT - 3/8" - 16NC |
3 |
|
|
|
|
? |
EJ2403 |
TUBE, INNER FRONT - RH |
1 |
|
|
|
|
? |
TB1019 |
GUARD, RAIN - LH |
1 |
|
|
|
|
? |
TR2961 |
CAPSCREW - 5/8" - 11NC X 1" |
4 |
|
|
|
|
? |
VC1390 |
LOCKWASHER - 5/8" |
4 |
|
|
|
|
? |
TR9082 |
FLAT WASHER - 5/8" |
4 |
|
|
|
|
? |
TB1406 |
GUARD, RAIN - FRONT |
1 |
|
|
|
|
? |
EJ2401 |
TUBE, OUTER REAR - RH |
1 |
|
|
|
|
? |
EJ1974 |
BENT TUBE, OUTER FRONT - RH |
1 |
|
|
|
|
? |
EJ9920 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
MM0004 |
CAPSCREW - M12 X 1.75 X 20 |
4 |
|
|
|
|
? |
MM0714 |
FLAT WASHER - M12 |
4 |
|
|
|
|
? |
EJ9919 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
TX6040 |
ELBOW, RUBBER - 45 DEG |
1 |
|
|
|
|
? |
WB1179 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
VW7882 |
HOSE |
1 |
|
|
|
|
? |
TB1018 |
GUARD, RAIN - RH |
1 |
|
|
|
|
? |
C1641 |
CAPSCREW - 5/8" - 11NC X 4 1/2" |
13 |
|
|
|
|
? |
C1541 |
LOCKWASHER - 5/8" |
13 |
|
|
|
|
? |
WA0361 |
FLAT WASHER - 5/8" |
13 |
|
|
|
|
? |
WA0471 |
CAPSCREW - 1/2" - 13NC X 2 1/4" |
5 |
|
|
|
|
? |
VC6500 |
CAPSCREW - 1/2" - 13NC X 2" |
3 |
|
|
|
|
? |
WA4728 |
FLAT WASHER - 1/2" |
32 |
|
|
|
|
? |
DF3500 |
LOCKNUT - 1/2" - 13NC |
16 |
|
|
|
|
? |
PC1247 |
ROD END |
16 |
|
|
|
|
? |
TL8151 |
JAM NUT - 1/2" - 20NF |
16 |
|
|
|
|
? |
EJ9909 |
CLAMP |
8 |
|
|
|
|
? |
VC4898 |
CAPSCREW - 1/2" - 13NC X 2 1/2" |
8 |
|
|
|
