| Наименование | Страница | Код страницы |
|---|---|---|
| A.F.S.E. PANEL COVER ASSEMBLY 1/2 58B-43-00480 | 700 | 64383 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4913 | SCREW (SPECIAL) | 5 | ||||
| ? | VE4604 | FLAT WASHER - #8 (NARROW) | |||||
| ? | VE4917 | CLAMP, CABLE | 3 | ||||
| ? | VS6662 | FLAT WASHER - #10 | |||||
| ? | VE4601 | LOCKWASHER - #10 | 9 | ||||
| ? | SF2755 | NUT - #10 - 32NF | 3 | ||||
| ? | 58B-43-00480 | PANEL COVER ASSEMBLY (SEE INDEX) | 1 | 64383 | |||
| ? | VE7202 | WASHER - 1/4" (SPECIAL) | |||||
| ? | DC3584 | LOCKWASHER - 1/4" | |||||
| ? | VE4650 | CAPSCREW - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | VE4907 | FLAT WASHER - 1/4" | 4 | ||||
| ? | VE4908 | LOCKWASHER - 1/4" | 4 | ||||
| ? | VE4909 | NUT - #4 - 40NC | 4 | ||||
| ? | VE4382 | RECEPTACLE | 2 | ||||
| ? | VE4383 | SCREW - #4 - 40NC X 1/2" | 4 | ||||
| ? | VE5098 | SUPPORT | 2 | ||||
| ? | VE5156 | CAPSCREW - #10 - 32NF X 7/8" | 4 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | |||||
| ? | VE6320 | CAPSCREW - 1/4" - 20NC X 1 1/8" | 10 | ||||
| ? | VE5130 | BAR, BUS | 1 | ||||
| ? | VE0297 | BAR, BUS | 2 | ||||
| ? | VE0036 | DIODE | 2 | ||||
| ? | GE1211 | RECTIFIER | 1 | ||||
| ? | GE1214 | RECTIFIER | 1 | ||||
| ? | 58B-43-00490 | CLAMP, CABLE - 5/16" | 1 | ||||
| ? | VP9525 | PIN | 4 | ||||
| ? | VE5136 | ROLLPIN | 2 | ||||
| ? | VE5128 | HEAT SINK | 2 | ||||
| ? | VE4915 | SCREW - #8 X 1/2" | 9 | ||||
| ? | VE4389 | SHIELD, INSULATION | 1 | ||||
| ? | GE1212 | RECTIFIER | 1 | ||||
| ? | GE1213 | RECTIFIER | 1 | ||||
| ? | VE3217 | BAR, BUS | 1 | ||||
| ? | VE4912 | SCREW - #8 X 5/8" | 5 | ||||
| ? | VE4604 | FLAT WASHER - #8 (NARROW) | |||||
| ? | VE4911 | HINGE | 1 | ||||
| ? | VE2604 | BAR, BUS | 1 |
