Содержание Dump Trucks Komatsu AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN)
CTRL CABINET - FRONT & REAR EXTERIOR 58E-43-00020(690 : 43451)
Номер на схеме Каталожный номер Название Количество Детали
? XA5287 CAPSCREW - 1/4" - 20NC X 7/8" 14
? XA5003 LOCKWASHER - 1/4" 14
? XA4233 FLAT WASHER - 1/4" 14
? XA5283 PIN, COTTER 2
? VE4655 FLAT WASHER - #10 2
? 58E-43-00480 RING, HOIST 2
? VE4542 CAPSCREW - 1/2" - 13NC X 1" 10
? VE4699 LOCKWASHER - 1/2" 10
? VE4519 FLAT WASHER - 1/2" 10
