Содержание Dump Trucks Komatsu AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN)
CONTROL CABINET - EXTERIOR 58E-43-00020(688 : 43450)
Номер на схеме Каталожный номер Название Количество Детали
? GE0857 PANEL 2
? VE4739 CAPSCREW - 3/8" - 16NC X 1"
? VE4515 FLAT WASHER - 3/8"
? 58B-43-00330 LATCH, DRAW 1
? 58B-43-00400 SCREW - #10 - 32NC X 1 1/4" 2
? 58E-43-00470 LOCKWASHER - #10 2
? VE4687 LOCKWASHER - 3/8"
? VE2338 CAPSCREW - 3/8" - 16NC X 3/4"
? VE4921 CAPSCREW - #10 - 32NF X 1"
? XA4570 PLUG, PIPE 2

Dump Trucks Komatsu / AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN) / CONTROL CABINET - EXTERIOR 58E-43-00020(688 : 43450)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
