Содержание Dump Trucks Komatsu AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN)
CTRL CABINET - LEFT COMPARTMENT 2/2 58E-43-00020(672 : 64392)
Номер на схеме Каталожный номер Название Количество Детали
? GE0865 CAPACITOR SUB-ASSEMBLY 1
? GE0514 • CAPACITOR 1
? GE1175 • CLAMP 1
? GE1176 • SUPPORT 1
? VE4343 FLAT WASHER - 5/16"
? GE1383 FLAT WASHER - 11/16"
? VE4696 LOCKWASHER - 5/16"
? VE5013 NUT - 5/16" - 18NC
? GE0755 POWER SUPPLY 1
? XA4233 FLAT WASHER - 1/4"
? XA5003 LOCKWASHER - 1/4"
? VE4902 NUT - 1/4" - 20NC
? GE0231 PANEL, FUSE 1
? XA4571 FUSE LIMITER (50 AMP) 1
? BF3908 SHIELD 1
? GE0170 SENSOR, AC-DC 2
? VE4655 FLAT WASHER - #10
? VE4601 LOCKWASHER - #10
? VE4602 NUT - #10 - 32NF
? XA5272 CAPSCREW - 3/8" - 16NC X 5/8" 2
? VE4687 LOCKWASHER - 3/8"
? VE4515 FLAT WASHER - 3/8"
? XA3591 SHIELD 1
? PB3348 INSULATOR 2
? GE0831 CAPSCREW - 3/8" - 16NC X 3/8" 1
? XA2784 WASHER 6
? 58B-43-00360 DOOR PROP ASSEMBLY 1
? 58B-43-00350 SHIELD, HV CABLE 1
? 58B-43-00280 LOCKNUT - 3/8" - 16NC 4
