Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PB9829 |
SCREW - M6 X 1.00 X 16 |
10 |
|
|
|
|
? |
WB2490 |
DECAL, WARNING (KEY SWITCH) |
1 |
|
|
|
|
? |
DC9822 |
DRIVE SCREW |
4 |
|
|
|
|
? |
EM4321 |
DASH MODULE, LOWER RH (SEE FIG 43365) |
1 |
|
43365 |
|
|
? |
EK8962 |
SEAL, LOWER MODULE |
2 |
|
|
|
|
? |
EL3495 |
DASH MODULE, UPPER RH (SEE FIG 60931) |
1 |
|
60931 |
|
|
? |
EK8961 |
SEAL, UPPER MODULE |
2 |
|
|
|
|
? |
EK7947 |
LOUVER, RECTANGULAR |
2 |
|
|
|
|
? |
EK7946 |
ADAPTER, HOSE |
2 |
|
|
|
|
? |
PB6926 |
GAUGE, FUEL LEVEL |
1 |
|
|
|
|
? |
PB8551 |
GAUGE, OIL PRESSURE |
1 |
|
|
|
|
? |
TW5472 |
INDICATOR, TURN |
2 |
|
|
|
|
? |
58E-06-02300 |
• BULB, LED |
1 |
|
|
|
|
? |
58E-06-02300 |
BULB, LED |
4 |
|
|
|
|
? |
PB6984 |
TACHOMETER, DIGITAL |
1 |
|
|
|
|
? |
TW3834 |
INDICATOR, HIGH BEAM |
1 |
|
|
|
|
? |
58E-06-02300 |
• BULB, LED |
1 |
|
|
|
|
? |
PC1175 |
SPEEDOMETER/DISPLAY |
1 |
|
|
|
|
? |
EL4151 |
CLAMP, GAUGE MOUNTING |
1 |
|
|
|
|
? |
PB6303 |
GAUGE, WATER TEMPERATURE |
1 |
|
|
|
|
? |
PB9868 |
GAUGE, HYDRAULIC OIL TEMPERATURE |
1 |
|
|
|
|
? |
EL1075 |
DASH PANEL, MOLDED |
1 |
|
|
|
|
? |
EL4149 |
DASH MODULE, UPPER LH (SEE FIG 42061) |
1 |
|
42061 |
|
|
? |
EL4146 |
DASH MODULE, LOWER LH (SEE FIG 60934) |
1 |
|
60934 |
|
|
? |
TX7829 |
SEAL, STEERING COLUMN |
1 |
|
|
|
|
? |
SM2646 |
PLATE, SEAL RETAINER - LH |
1 |
|
|
|
|
? |
SM2648 |
PLATE, SEAL RETAINER - RH |
1 |
|
|
|
|
? |
SM2785 |
HOURMETER |
1 |
|
|
|
|
? |
PB8658 |
SCREW - M6 X 1.00 X 30 |
4 |
|
|
|
|
? |
SM2783 |
HOSE, AIR (TO RECTANGULAR LOUVERS) |
2 |
|
|
|
|
? |
CC6103 |
CLAMP, WORM DRIVE (FOR AIR HOSES) |
4 |
|
|
|
|
? |
WA4513 |
SCREW - #10 - 24NC X 1/2" (1) |
4 |
|
|
|
|
? |
SM5145 |
TUBE (1) |
2 |
|
|
|
|
? |
|
NOTE: (1) NOT INCLUDED IN EM4322 INSTRUMENT PANEL ASSEMBLY. |
|
|
|
|
