Содержание Dump Trucks Komatsu AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN)
VISOR INSTALLATION(192 : 42444)
Номер на схеме Каталожный номер Название Количество Детали
? EK2770 SHEET, FORMED 2
? PB9829 SCREW - M6 X 1.00 X 16 4
? SM0926 SCREW - M6 X 1.00 10
? PB8658 SCREW - M6 X 1.00 X 30 1
? SM5244 VISOR, LENS 2
? 31127R1 CAPSCREW - M6 X 1.00 X 12 6
? MM0207 LOCKWASHER - M6 6
? XC2375 CLOSURE, FRONT 1

Dump Trucks Komatsu / AFE57-FN 830E-1AC S/N A30688-A30689, A30698-A30703, A30705-A30708, A30713-A30714, A30728-A30731, A30736-A30737, A30749-A30752, A30756, A30776-A30778, A30788-A30790, A30803, A30805-A30806, A30817, A30834 & A30847 - A30850 BROCKMAN / HOPE DO(AFE57-FN) / VISOR INSTALLATION(192 : 42444)
?
?
?
?
?
?
?
?
?
