| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB3719 | LIGHT, AMBER LED | 2 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 6 | ||||
| ? | WB3097 | CLAMP, CUSHION - 1/2" | 3 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 16 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 19 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 19 | ||||
| ? | EK9380 | LIGHT, RED PLM | 1 | ||||
| ? | EK9381 | LIGHT, YELLOW PLM | 1 | ||||
| ? | EK9382 | LIGHT, GREEN PLM | 1 | ||||
| ? | TG1929 | SCREW - #10 - 24NC X 1/2" | 12 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 12 | ||||
| ? | DF0017 | NUT - #10 - 24NC | 12 | ||||
| ? | TV3555 | PLUG, BUTTON - 1 3/8" | 1 | ||||
| ? | VN0137 | CLAMP, CUSHION - 7/16" | 8 | ||||
| ? | VC6041 | GROMMET, RUBBER | 1 | ||||
| ? | DC5004 | SCREW - #12 - 24NC X 1/2" | 4 | ||||
| ? | VD2047 | LOCKWASHER - #12 | 4 | ||||
| ? | EL9830 | COVER | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 3 | ||||
| ? | WB3093 | CLAMP, CUSHION - 1" | 3 |
