| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9566 | DRIVE SHAFT W/SPLINE | 1 | ||||
| ? | VE9568 | BEARING | 1 | ||||
| ? | VE9570 | RING, RETAINER | 1 | ||||
| ? | VE9569 | RING, RETAINER | 1 | ||||
| ? | VE9535 | BOLT, EYE | 2 | ||||
| ? | VE9545 | PLATE, NAME | 1 | ||||
| ? | VE9544 | DRIVE SCREW | 8 | ||||
| ? | VE9542 | PLATE, NAME | 1 | ||||
| ? | VE9538 | PLUG | 3 | ||||
| ? | VE9540 | O-RING | 3 | ||||
| ? | VE9543 | PLATE, NAME | 1 | ||||
| ? | VE9597 | STEM | 1 | ||||
| ? | VE9598 | O-RING | 1 | ||||
| ? | VE9595 | GLAND | 1 | ||||
| ? | 58E-98-00050 | SEAL, O-RING (1) | 2 | ||||
| ? | BF3733 | JAM NUT | 1 | ||||
| ? | VE9534 | BEARING, RETAINING PIN | 2 | ||||
| ? | VE9546 | O-RING | 3 | ||||
| ? | VE9562 | PIN, SWASH BLOCK | 2 | ||||
| ? | VE9530 | HOUSING, PUMP | 1 | ||||
| ? | VE9567 | RETAINER, SEAL | 1 | ||||
| ? | BF0293 | O-RING | 2 | ||||
| ? | VE9536 | PLUG | 1 | ||||
| ? | VE9532 | SEAL, SHAFT | 1 | ||||
| ? | VE9607 | PLUG | 1 | ||||
| ? | 58E-98-00000 | NOTE: (1) INCLUDED IN 58E-98-00000 PUMP SEAL KIT. |
