| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EH7494 | SEAL, STRIP | 1 | ||||
| ? | EL5801 | SEAL, STRIP | 1 | ||||
| ? | 58E-43-00020 | CONTROL CABINET (SEE SECTION P) | 1 | ||||
| ? | MM0124 | CAPSCREW - M30 X 3.50 X 90 | 9 | ||||
| ? | MM0467 | FLAT WASHER - M30 | 9 | ||||
| ? | MM0477 | LOCKWASHER - M30 | 9 | ||||
| ? | MM0184 | NUT - M30 X 3.50 | 9 | ||||
| ? | VC6561 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 13 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 10 | ||||
| ? | VC7836 | FLAT WASHER - 1/2" | 4 | ||||
| ? | PC2368 | BRACKET, SUPPORT | 1 | ||||
| ? | VG7811 | LOCKNUT - 1/2" - 13NC | 2 | ||||
| ? | EK7544 | SEAL STRIP | 3 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" | 7 | ||||
| ? | EL5801 | SEAL, STRIP | 1 | ||||
| ? | XB9201 | SHEET, BENT | 1 | ||||
| ? | MM0607 | CAPSCREW - M10 X 1.50 X 35 | 8 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 8 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 8 | ||||
| ? | XB9203 | SHEET, BENT | 1 | ||||
| ? | EL9860 | TRANSITION | 1 | ||||
| ? | EK7594 | GASKET | 1 | ||||
| ? | H8620 | CAPSCREW - 5/16" - 18NC X 1 1/4" | 12 | ||||
| ? | E3735 | FLAT WASHER - 5/16" | 12 | ||||
| ? | C1538 | LOCKWASHER - 5/16" | 12 |
