Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
BF5349 |
TANK, SURGE (INCLUDED IN RADIATOR ASSEMBLY) |
1 |
|
|
|
|
? |
PC2800 |
RADIATOR AND SHROUD ASSEMBLY (SEE INDEX) |
1 |
|
42945 |
|
|
? |
E3909 |
CAPSCREW - 1" - 8NC X 3 1/4" |
2 |
|
|
|
|
? |
VH8186 |
LOCKNUT - 1" - 8NC |
4 |
|
|
|
|
? |
C1532 |
NUT, HEX |
10 |
|
|
|
|
? |
PB6831 |
END, ROD |
2 |
|
|
|
|
? |
TY5096 |
ROD, THREADED |
2 |
|
|
|
|
? |
C1667 |
CAPSCREW - 1" - 8NC X 2 1/2" |
2 |
|
|
|
|
? |
MM0038 |
CAPSCREW - M16 X 2.00 X 35 |
8 |
|
|
|
|
? |
MM0706 |
FLAT WASHER - M16 |
8 |
|
|
|
|
? |
58E-80-20400 |
SUPPORT, RADIATOR |
2 |
|
|
|
|
? |
58E-80-20300 |
BRACKET |
2 |
|
|
|
|
? |
ED9895 |
FLAT WASHER |
8 |
|
|
|
|
? |
PC0780 |
MOUNT, RUBBER - TWO PIECE |
4 |
|
|
|
|
? |
C1648 |
CAPSCREW - 3/4" - 10NC X 3" |
8 |
|
|
|
|
? |
WA0362 |
FLAT WASHER - 3/4" |
8 |
|
|
|
|
? |
C1542 |
LOCKWASHER - 3/4" |
8 |
|
|
|
|
? |
C1527 |
NUT - 3/4" - 10NC |
8 |
|
|
|
