| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA5788 | ROTOR ASSEMBLY | 1 | ||||
| ? | XA5789 | • ROTOR ASSEMBLY (WITH DRIVE RING) | 1 | ||||
| ? | XA5790 | • ROTOR ASSEMBLY (LESS TRANS) | 1 | ||||
| ? | XA4038 | PUNCHING, HEAD | 2 | ||||
| ? | XA2860 | END PLATE, ROTOR | 1 | ||||
| ? | XA2861 | END RING, ROTOR | 2 | ||||
| ? | XA4575 | NUT | 1 | ||||
| ? | GE0123 | LOCKWASHER | 1 | ||||
| ? | VS8255 | WEIGHT (1) | |||||
| ? | VE7207 | COLLAR | 1 | ||||
| ? | XA2866 | FRAMEHEAD | 1 | ||||
| ? | VE7211 | HOUSING, BEARING | 1 | ||||
| ? | XA2867 | BEARING, ROLLER (1) | 1 | ||||
| ? | VE4536 | COLLAR | 1 | ||||
| ? | VJ9656 | LIQUID GASKET | |||||
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" (1) | 8 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" (1) | 8 | ||||
| ? | BF1660 | SEAL, TEFLON | 1 | ||||
| ? | BF2112 | CAP, BEARING | 1 | ||||
| ? | XA2871 | CLEAT, SUPPORT | 1 | ||||
| ? | XA2872 | CLEAT, CABLE | 2 | ||||
| ? | XA2873 | PLATE | 1 | ||||
| ? | GE0796 | LOCKNUT - 3/8" - 16NC | 2 | ||||
| ? | VE7212 | SEAL, V-RING (1) | 1 | ||||
| ? | VE5184 | FLAT WASHER - 5/8" (1) | 32 | ||||
| ? | GE0141 | CAPSCREW - 5/8" - 11NC X 2 1/4" | 12 | ||||
| ? | VE4739 | CAPSCREW - 3/8" - 16NC X 1" | 3 | ||||
| ? | GE0040 | CAPSCREW (1) | 2 | ||||
| ? | VE3027 | FLAT WASHER - 3/8" (1) | 7 | ||||
| ? | AK9363 | NOTE: (1) INCLUDED IN AK9363 WHEEL MOTOR OVERHAUL KIT. |
