| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE0500 | BEARING, INBOARD (1) | 1 | ||||
| ? | VE7201 | O-RING (1) | 1 | ||||
| ? | VE4744 | RING, SEAL | 1 | ||||
| ? | BF1484 | CAPSCREW - 1" - 14NF X 5 1/2" (1) | 45 | ||||
| ? | XA4287 | FLAT WASHER - 1" (1) | 45 | ||||
| ? | VE6091 | HUB, WHEEL | 1 | ||||
| ? | VE0499 | BEARING, OUTBOARD (1) | 1 | ||||
| ? | VE4234 | CAP, BEARING | 1 | ||||
| ? | VE4745 | CAPSCREW - 3/4" - 10NC X 2 1/2" (1) | 24 | ||||
| ? | VE5188 | FLAT WASHER - 3/4" (1) | 24 | ||||
| ? | XA4289 | CABLE, SPEED SENSOR (1) | 1 | ||||
| ? | XA4288 | SENSOR, SPEED (1) | 1 | ||||
| ? | XA2864 | BAFFLE | 1 | ||||
| ? | XA2863 | RING | 1 | ||||
| ? | VE4739 | CAPSCREW - 3/8" - 16NC X 1" (1) | 8 | ||||
| ? | VE3027 | FLAT WASHER - 3/8" | 8 | ||||
| ? | XA2858 | PUNCHING, MAIN | 860 | ||||
| ? | XA2862 | SHAFT, ROTOR | 1 | ||||
| ? | VE0517 | SEAL (1) | 1 | ||||
| ? | VE0662 | BAND, WEAR (1) | 1 | ||||
| ? | VE4641 | CAPSCREW - 3/8" - 16NC X 1 1/4" (1) | 12 | ||||
| ? | VE3027 | FLAT WASHER - 3/8" (1) | 12 | ||||
| ? | VE4746 | RING, SEAL | 1 | ||||
| ? | VE4785 | RING, ADAPTER | 1 | ||||
| ? | VE0667 | CAPSCREW - 1" - 8NC X 5" (1) | 9 | ||||
| ? | VE4784 | FLAT WASHER - 1" (1) | 9 | ||||
| ? | VE4499 | CAPSCREW - 5/8" - 11NC X 1 1/2" (1) | 10 | ||||
| ? | VE2466 | RING, THRUST | 1 | ||||
| ? | VE0663 | SHIM SET (1) | 1 | ||||
| ? | VE4501 | • SHIM - 0.005" X 20.9" | 8 | ||||
| ? | VE4502 | • SHIM - 0.007" X 20.9" | 16 | ||||
| ? | VE4503 | • SHIM - 0.0299" X 20.9" | 28 | ||||
| ? | VE4504 | • SHIM - 0.005" X 14.67" | 5 | ||||
| ? | VE4505 | • SHIM - 0.007" X 14.67" | 4 | ||||
| ? | VE4506 | • SHIM - 0.0299" X 14.67" | 2 | ||||
| ? | XA4040 | CAPSCREW (1) | 20 | ||||
| ? | VE5184 | FLAT WASHER - 5/8" (1) | 10 | ||||
| ? | XA2854 | STATOR ASSEMBLY | 1 | ||||
| ? | XA2855 | KIT, STATOR REWIND | 1 | ||||
| ? | XA2856 | KIT, STATOR BUS | 1 | ||||
| ? | AK9363 | NOTE: (1) INCLUDED IN AK9363 WHEEL MOTOR OVERHAUL KIT. |
