| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4064 | SEAL, DUST (1) | 1 | ||||
| ? | VE3080 | HOUSING/SPOOL/SLEEVE | 1 | ||||
| ? | VE3081 | BALL | 1 | ||||
| ? | VE3082 | BUSHING, THREADED | 1 | ||||
| ? | BF3031 | O-RING (1) | 1 | ||||
| ? | BF3282 | KIN-RING (1) | 1 | ||||
| ? | VE3083 | BEARING ASSEMBLY | 1 | ||||
| ? | VE3084 | RING | 1 | ||||
| ? | VE3085 | PIN, CROSS | 1 | ||||
| ? | VE3086 | SET, SPRING | 1 | ||||
| ? | VE3087 | SHAFT, CARDAN | 1 | ||||
| ? | VE3094 | SPACER | 1 | ||||
| ? | VE3088 | SPACER | 1 | ||||
| ? | VE4069 | O-RING (1) | 1 | ||||
| ? | VE3089 | PLATE, DISTRIBUTOR | 1 | ||||
| ? | VE3090 | SET, GEAR WHEEL | 1 | ||||
| ? | VE4071 | O-RING (1) | 2 | ||||
| ? | VE3091 | COVER, END | 1 | ||||
| ? | VE4072 | WASHER (1) | 7 | ||||
| ? | VE3092 | PIN, ROLL | 1 | ||||
| ? | VE3093 | CAPSCREW - M8 X 90 MM | 1 | ||||
| ? | MM0401 | CAPSCREW - M8 X 1.25 X 90 | 6 | ||||
| ? | PLATE, NAME (2) | 1 | |||||
| ? | DRIVE SCREW (2) | 2 | |||||
| ? | BF3287 | NOTE: (1) INCLUDED IN BF3287 SEAL KIT. | |||||
| ? | (2) NOT SERVICED SEPARATELY. |
