| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING CYLINDER AND BEARINGS | 548 | 41812 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | KC7131 | CAPSCREW - 1" - 8NC X 9 1/2" (1) | 4 | ||||
| ? | EF7971 | PIN (1) | 4 | ||||
| ? | EK3377 | SEAL, BEARING (1) | 8 | ||||
| ? | EK3376 | SPACER (1) | 8 | ||||
| ? | PC1682 | BEARING, SPHERICAL (1) | 4 | ||||
| ? | EL7952 | STEERING CYLINDER ASSEMBLY (SEE FIG 41812) | 2 | 41812 | |||
| ? | EK3384 | RETAINER, ANTI-ROTATION (1) | 4 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 32 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 32 | ||||
| ? | EF7970 | WASHER | 4 | ||||
| ? | EG1853 | RETAINER (1) | 4 | ||||
| ? | VN9755 | LOCKNUT - 1" - 8NC (1) | 4 | ||||
| ? | AK5108 | NOTE: (1) INCLUDED IN AK5108 STEERING CYLINDER | |||||
| ? | AND TIE ROD PIN KIT. |
